Power

15kw

Log Dia.

711 mm

Max. Cut

4572 mm

Horizontal Wood Band Re-saw | MJ357A

Price:

  • User-friendly PC interface for simple and convenient operation
  • High-precision rotary encoder in combination with precision ball screw to control the sawing thickness at higher precision.
  • Assisted revert system is safe and reliable, saving labor and time.
  • PLC integrated control system is safe and reliable.
  • Hydraulic saw blade tension auto-compensation system ensuring saw blade to be always at the best tension state to prolong the service life of saw blade.
  • Hydraulic motor drive is used for conveyor belt, performing stably and constantly and powerfully and ensuring operation to be flat and smooth.
  • Specially designed multi-set pressing device ensuring wood to be reliably pressed during sawing to guarantee safe operation.
  • Saw blade cooling, lubricating and dedusting system ensuring cooling, lubricating an dedusting of saw blade at one go safely and in an unpolluted way.
Quick Inquiry Download PDF

1-Year Warranty

Related Parts & Accessories

Add a Short Title Here

Use this space to add a short description. It gives enough info to earn a click.

Add a Short Title Here

Use this space to add a short description. It gives enough info to earn a click.

Add a Short Title Here

Use this space to add a short description. It gives enough info to earn a click.

Add a Short Title Here

Use this space to add a short description. It gives enough info to earn a click.

Add an overline

Craft a captivating title for this section to attract your audience.

Call To Action

About This Product

Product ModelMJ357A×250MJ357A×400
Max. sawing size(saw blade lifted to 60 mm)250×200mm400×200mm
Distance from saw blade to worktable3~80mm3~80mm
Width of conveyor belt235mm385mm
Saw wheel diameter711mm711mm
Feeding speed0~18m/min0~18m/min
Lifting motor0.18kw0.18kw
Saw wheel motor15kw18.5 kw
Hydraulic pressure55kg/cm255kg/cm2
Suction pipe diameter102mm×2102mm×2
Saw blade size (L×W×T)4572×27×0.9 mm (1″ saw wheel)4572× 41× 1.27 mm (1.5″ saw wheel)4572×27×0.9 mm (1″ saw wheel)4572× 41× 1.27 mm (1.5″ saw wheel)
Saw Kerfs1.2~2.2mm1.2~2.2mm
Dimensions (L×W×T)3000×2230×2050mm3000×2230×2050mm
Weight1700kg1900kg

video

Related Product

FAQ

Your woodworking machinery Success Starts with Nanyang

At Nanyang, we strive to provide superior services and solutions that surpass your expectations. Let us find the ideal woodworking machinery solution for your project.

We will respond to you within 24 hours after receiving your inquiry.

We are one of the factories with production, sales, after-sales. Real factory price and service.

Our main products are: wood band saws and carriages; wood drying equipment. Other products are: saw blade sharpening machines; saw blade rolling machines, saw blade welding machines, etc.

Woodworking band saws and sports cars involve application areas: furniture, flooring, wood boards, building materials, handicrafts, wood, wood packaging and other wood products enterprises. The application of wood drying kilns involves: furniture, flooring, wood boards, building materials, handicrafts, wood, wood packaging and other wood products enterprises.

Fully customizable, we have R&D team.

Annual output value is 50 million yuan.

The company currently has 100 employees, including more than 20 professional and technical personnel.

We will conduct corresponding tests after each process is completed. For the final product, we will do 100% comprehensive inspection according to customer requirements and industry standards.

When quoting, we will confirm the transaction method with you, FOB, CIF, CNF or other methods. Generally, customers pay 30% advance payment in advance, and the balance is paid before the factory ships. We mostly pay by T/T, of course, L/C is acceptable.

Usually we ship by sea, but railway and land transportation are also very convenient.

Nanyang Machinery has more than 2,000 users in China and around the world. In Southeast Asia (Indonesia, the Philippines, Malaysia, Myanmar, Vietnam and Laos), Africa (Gabon, Benin, Congo, Togo, Nigeria, Angola, Ghana), South America (Chile, Uruguay, Brazil, Suriname, Guyana), Ukraine, Romania, Kazakhstan) and Japan, North Korea and more than 30 other countries, it enjoys a very good reputation among users, furniture, flooring, wood boards, building materials, handicrafts, wood, wood packaging and other dry wood products companies.
